Forklift, Telescopic, 42' 8,000 lbs. (Mustang 842)

Forklift, Telescopic, 42' 8,000 lbs. (Mustang 842)

Specs (Specifications may change due to continuous product development)

Mustang Model 842 Telehandler Specifications
Capacities
Lift Capacity (kg)	8,000 lbs. (3629)
Maximum Lift Height (m)	42' (12.8)
Capacity @ Maximum Lift Height (kg)	7,000 lbs. (3175)
Maximum Forward Reach (m)	28' 3' (8.6)
Capacity at Maximum Reach (kg)	1,000 lbs. (453)
Maximum Reach Below Grade (mm)	1' 2" (356)
Engine
Type	John Deere
Power (kW)	Std. 115 hp (86)
Aspiration	Turbocharged
Model	4045T
Components
Transmission - Power Shift	Clark 3-Speed
Drive (Full-Time)	4-Wheel
Steering	4-Wheel 2-Wheel Crab
Brakes, 4-Wheel Hydraulic	Internal Wet Disc
Parking Brake	SAHR (Spring-Applied, Hydraulic-Release)
Axle Manufacturer	Dana
Hydraulic System
Pump Type	Gear
Flow Capacity (L/min)	40 GPM (151)
System Pressure (bar)	3,000 PSI (207)
Hydraulic Reservoir Capacity (L)	47 Gallon (178)
General Specifications
Approximate Weight (kg)	23,350 lbs. (10,660)
Length - Less Forks (m)	19' 1" (5.82)
Width (m)	8' 2.4" (2.5)
Ground Clearance (mm)	1' 4" (406)
Wheelbase (m)	10' 3" (3)
Turning Radius (m)	13' 8" (4.2)
Overall Height (m)	7' 8" (2.3)
Frame Leveling	+ 10°
Fuel Tank Capacity (l)	47 Gallons (178)
Work Platform Station (WPS)	Optional
Additional Options	All Weather Cab, Lights, Tire Options, Cold Start Kit, Clutch Cut-Out, Special Paint, Auxiliary Hydraulics, Outrigger Package, Centrifugal Pre-Cleaner Package.
Tire Options	13.00 x 24/12 PR 13.00 x 24/12 PR Foam-Filled 13.00 x 24/12 PR - Rock
