Forklift, Telescopic, 55' 11,000 lbs. (Mustang 1155)

Specs (Specifications may change due to continuous product development)

Mustang Model 1155 Telehandler Specifications
Capacities
Lift Capacity (kg)	11,000 lbs. (4990)
Maximum Lift Height (m)	55' 1"(16.7)
Capacity @ Maximum Lift Height (kg)	5,500 lbs. (2495)
Maximum Forward Reach (m)	40' 9' (12.4)
Capacity at Maximum Reach (kg)	2,000 lbs. (907)
Maximum Reach Below Grade (mm)	23" (584)
Engine
Type	John Deere
Power (kW)	Std. 115 hp (86)
Rated Speed	2,500 rpm
Aspiration	Turbocharged
Number of Cylinders	4
Displacement (L)	276 cu. in. (4.5L)
Model	4045T
Drive Train
Transmission Type	Power Shift
Number of Speeds (fwd/rev)	4/2
Maximum Travel Speed (km)	22.8 mph (37)
Steering System	4WS (3 mode)
Service Brake Type	Wet Multiple Disc
Parking Brake Type	Spring Applied/Hydraulic Release
Tire Size	14.00 x 24
Hydraulic System
Pump Type	Dual Gear
Flow Capacity (L/min)	43 GPM (163)
System Pressure (bar)	3,000 PSI (207)
Hydraulic Reservoir Capacity (L)	45 Gallon (170)
Dimensions
Approximate Weight (kg)	28,460 lbs. (12,990)
Length - Less Forks (m)	21' 2" (6.4)
Width (m)	8' 3" (2.5)
Ground Clearance (mm)	16" (406)
Wheelbase (m)	10' 8" (3.2)
Turning Radius Over Tires, Brakes Off (m)	7' 11" (2.4)
Overall Height, Boom Down (m)	7' 8" (2.3)
Frame Leveling	+ 10°
Fuel Tank Capacity (l)	47 Gallons (178)
