You are here: Home > New Equipment > Aerial Lifts > Forklifts, Telescopic

Forklift, Telescopic, 19' 5,500 lbs. (Mustang 519) Overview Description Specs Brochures/Manuals Specs (Specifications may change due to continuous product development) Mustang Model 519 Telehandler Specifications Capacities Lift Capacity (kg) 5,500 lbs. (2495) Maximum Lift Height (m) 19'1" (5.8) Capacity @ Maximum Lift Height (kg) 3,000 lbs. (1360) Maximum Forward Reach (m) 11' (3.35) Capacity at Maximum Reach (kg) 1,850 lbs. (839) Maximum Reach Below Grade (mm) 0" (0) Engine Type Deutz - 4-Cylinder Diesel Power (kW) 64 hp (48) Aspiration Turbocharged Model TD2009 L04 Rated Speed 2750 rpm Components Transmission Rexroth 2-Speed Hydrostatic Maximum Travel Speed (km/h) 15 mph (24) Steering 4-Wheel 2-Wheel Crab Service Brakes Internal Wet Disc 2-Wheel Hydraulic Parking Brake SAHR (Spring-Applied, Hydraulic-Release) Axle Manufacturer Dana Hydraulic System Pump Type Gear Flow Capacity (L/min) 22 GPM (83) System Pressure (bar) 3,350 PSI (231) Hydraulic Reservoir Capacity (L) 18 Gallon (68) General Specifications Approximate Weight (kg) 10,000 lbs. (4536) Length - Less Forks (m) 12'4" (3.76) Width (m) 5'11" (1.80) Ground Clearance (mm) 14" (350) Wheelbase (m) 7'6" (2.29) Turning Radius (m) 11' (3.35) Overall Height (m) 6'4" (1.93) Fuel Tank Capacity (l) 17 Gallons (64) Attachment Options Bucket & Truss Boom Tire Options 12.00 x 16.5 Bias/10 PR) 12.00 x 16.6 Bias/10 PR - Foam-Filled

---

We know your business success depends on reliable quality equipment and parts to continue being a leader in your industry. When you want Genuine Mustang original equipment parts, accessories and equipment you can always depend on Discount-Equipment.com to come through with the genuine o.e.m. products you need as quickly and inexpensive as possible. Our sales staff combined experience consists of over 90 years in the construction parts and equipment industry. We have over 1 million items online, if you are having trouble finding your item, we also have the resources to help you find what you need, our industry leading web site includes thousands of parts and service manuals available to look up your items. If you don't find what you are looking for please fill out our parts request form here.
