You are here: Home > New Equipment > Generators > Generators - Portable

Winco WC12000HE Generator,12000 Watt Honda Overview Description Specs Brochures/Manuals Specs (Specifications may change due to continuous product development) I believe we have the air filters. Model WL12000HE DB Rating @ 7 meters (23 ft.) 78.50 dBA Electrical Specifications Maximum Power Rating (watts) 12000 Continuous Power Rating (watts) 10800 A.C. Output Voltage @ 60 Hz. 120 / 240 volts Power Factor (pf) 1.0 pf Continuous Current Rating (A.C. amps) 45.0 amps @ 240 volts Motor Starting Ability (hp) 6 hp Generator Type (R.F.B. / R.F.L. / R.A.B.) R.F.L. Hour Meter Standard Voltage Regulation +/- 6% Mechanical Specifications Generator Speed (rpm) 3600 rpm Brushless Yes Single Point Lifting Eye Standard Engine Specifications Make / Model Honda / GX620 Displacement / Type 620 cc / OHV Rated Power @3600 rpm 20 HP Engine Speed 3600 rpm Conserver Automatic Idle Control Standard Low Oil Protection Standard Starting System Electric Cooling System Air Recommended Battery Size (Group/CCA) U1 - 235 cca Gasoline Information Fuel Tank Capacity 15 gallons Running Time (Full Load) 9.0 hours Running Time (Half Load) 14.5 hours 120 Volt Receptacles Straight Blade (NEMA 5-15R) 2 - 15 amp Straight Blade (NEMA 5-20R) GFCI 2 - 20 amp GFCI Straight Blade (NEMA L5-20R) 1 - 20 amp GFCI 240 Volt Receptacles Twist Lock (NEMA L6-30R) 1 - 30 amp 120 / 240 Volt Receptacles Straight Blade (NEMA 14-60R) 1 - 60 amp Circuit Breakers Main Breaker Standard Other Circuit Breakers Standard Size & Weight L x W x H( in.)† 39 x 26 x 26 in. Ship Weight (lbs.) 378 lbs. Warranty Information Generator 1 yrs Engine 2 yrs Accessories 2 Wheel Dolly Kit Included Transfer Switches EMER-TRANS SYS/SW60/30 Suggested

---
