Winco WL18000VE Generator, 18000 Watt, VANGUARD 24018-002 Overview Description Specs Operations Brochures/Manuals Specs (Specifications may change due to continuous product development) Model    WL18000VE  DB Rating @ 7 meters (23 ft.)    79.25 dBA  Electrical Specifications  Maximum Power Rating (watts)   18000  Continuous Power Rating (watts)   15000  A.C. Output Voltage @ 60 Hz.   120 / 240 volts  Power Factor (pf)   1.0 pf  Continuous Current Rating (A.C. amps)   62.5 amps @ 240 volts  Motor Starting Ability (hp)   7.5 hp  120 Volt Full Power   125 amps  Generator Type (R.F.B. / R.F.L. / R.A.B.)   R.F.L.  Hour Meter   Standard  Voltage Regulation   +/- 5%  Frequency Regulation (Nl To Fl)   +/- 3%  Mechanical Specifications  Generator Speed (rpm)   3600 rpm  Brushless   Yes  Single Point Lifting Eye   Standard  Engine Specifications  Make / Model   B&S / Vanguard  Displacement / Type   895 cc / OHV  Rated Power @3600 rpm   31 HP  Engine Speed   3600 rpm  Low Oil Protection   Standard  Starting System   Electric  Cooling System   Air  Recommended Battery Size (Group/CCA)   U1 - 235 cca  Gasoline Information  Fuel Tank Capacity   15 gallons  Running Time (Full Load)   6.8 hours  Running Time (Half Load)   10.5 hours  120 Volt Receptacles  Straight Blade (NEMA 5-15R)   4 - 20 amp GFCI  Straight Blade (NEMA 5-20R) GFCI   2 - 20 amp  Straight Blade (NEMA 5-50R)   1 - 50 amp  240 Volt Receptacles    Twist Lock (NEMA L6-30R)   1 - 30 amp  120 / 240 Volt Receptacles    Straight Blade (NEMA 14-60R)   1 - 60 amp  Circuit Breakers    Main Breaker   Standard  Other Circuit Breakers   Standard  Size & Weight  L x W x H( in.)†   41 x 26.75 x 29 in.  Ship Weight (lbs.)   550 lbs.  Warranty Information  Generator   2 yrs  Engine   1 yrs - Winco WL18000VE/WL120000HE Clicking on any of the above links will direct you to independently managed World Wide Web Sites which are not affiliated with RenTrain or this Rental Store. While every effort has been made to evaluate the sites to which we link, we cannot control the content that may appear on these or related links.

---
