Generac Magnum MLT5060M / MLT5060K / MLT5080M / MLT5080K Frame Assembly

  • Hover over the parts to see the part number
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part



Frame Assembly
Coupler Hitch 16835B 16999B Spacer Spacer Spacer Coupler Coupler Jack Assembly Weldment Outrigger Weldment Jack Assembly Weldment Screw Washer Plunger Kit Breakaway Kit Bracket 15580 Nut Washer Jack Assembly Screw Washer Weldment Washer Nut Outrigger Weldment Pin Lug nut Wheel Screw 17797 17797 Nut Axle Tie Plate U-Bolt Wheel Stud Bearing Seal Inner Bearing 11276 Roller Bearing Jack Assembly Weldment Nut Washer Screw Safety Chain Weldment Screw Washer Washer Nut Hitch 13688B

11672B

111672B Hitch 3.00x1.625 ring/2.50 tube Generac Magnum MLT5060 Light Tower

Your Price: $230.19

Click For Price and Specs

11276

11276 Hub w/races 3500LB MLT Generac Magnum Light Tower

Your Price: $130.29

Click For Price and Specs

11277

11277 U-bolt 3500LB MLT Generac Magnum Light Tower

Your Price: $13.63

Click For Price and Specs

11278

11278 Tie plate 3500LB MLT Generac Magnum Light Tower

Your Price: $14.68

Click For Price and Specs

11511

11511 Axis Axle roller bearing Generac Magnum Light Tower

Your Price: $25.18

Click For Price and Specs

11965Z

11965Z Weldment, jack adapter Generac Magnum Light Tower

Your Price: $33.46

Click For Price and Specs

12122

12122 Axle, 3500 lb 56SC 68.5TC elec brake Generac Magnum Light Tower

Your Price: $479.00

Click For Price and Specs

12155B

12155B Spacer, coupler - black Generac Magnum Light Tower

Your Price: $47.74

Click For Price and Specs

12217B

12217B Bracket, brake lever mounting Generac Magnum Light Tower

Your Price: $16.93

Click For Price and Specs

12307

12307 Bearing Seal DL350 Generac Magnum Light Tower

Your Price: $13.11

Click For Price and Specs

12408Z

12408Z Weldment, outrigger Generac Magnum Light Tower

Your Price: $117.37

Click For Price and Specs

12420B

12420B Weldment, removable tongue Generac Magnum Light Tower

Your Price: $168.29

Click For Price and Specs

13003B

13003B Coupler, 2.00 ball/3/00 channel Generac Magnum Light Tower

Your Price: $226.69

Click For Price and Specs

13050

13050 (11978) Jack Assembly 2000 lb. Side Wind Generac Magnum Light Tower

Your Price: $102.78

Click For Price and Specs

13051

13051 (23254) Jack Assembly 2000# Top Wind Generac Magnum Light Tower

Your Price: $104.04

Click For Price and Specs

13688B

13688B Weldment, chassis - open Generac Magnum Light Tower

Your Price: $1,299.00

Click For Price and Specs

14324

14324 Kit, plunger Generac Magnum Light Tower

Your Price: $35.86

Click For Price and Specs

15540

15540 Wheel, ST205/75R15, 1820# 6 PR Generac Magnum Light Tower

Your Price: $279.99

Click For Price and Specs

15580

15580 Park Brake Kit Generac Magnum MLT5060M MLT5060K MLT5080M MLT5080K Light Tower

Click For Price and Specs

16830

16830 Coupler, 2.00 ball/2.50 channel Generac Magnum Light Tower

Your Price: $53.50

Click For Price and Specs

16835B

16835B Weldment, lunette ring - 3.00 ID Generac Magnum Light Tower

Your Price: $157.09

Click For Price and Specs

16999B

16999B Weldment, lunette ring - 2.50 ID Generac Magnum Light Tower

Your Price: $96.58

Click For Price and Specs

17797

17797 Plate, shackle bracket Generac Magnum Light Tower

Your Price: $2.13

Click For Price and Specs

17807B

17807B (12229) Coupler 2.31 ball/3.00 channel Generac Magnum MLT5060 Light Tower

Your Price: $275.99

Click For Price and Specs

19417

19417 Breakaway kit Generac Magnum Light Tower

Your Price: $96.58

Click For Price and Specs

23367

23367 Chain, safety - 7,800 lbs. rated Generac Magnum Light Tower

Your Price: $34.54

Click For Price and Specs

23505

23505 Cable, pin tether 12" Generac Magnum Light Tower

Your Price: $10.05

Click For Price and Specs

40954

40954 Inner bearing Generac Magnum Light Tower

Your Price: $21.28

Click For Price and Specs

50215

50215 Screw, .500-13x4.000 std hex G5 Generac Magnum Light Tower

Your Price: $6.63

Click For Price and Specs

60096

60096 Nut, .500-20 wheel lug Generac Magnum Light Tower

Your Price: $6.99

Click For Price and Specs

60358

60358 Nut, .375-16 nylk G5 Generac Magnum Light Tower

Your Price: $15.58

Click For Price and Specs

60416

60416 Washer, .500 flat 1.375/.090 Generac Magnum Light Tower

Your Price: $13.65

Click For Price and Specs

60503

60503 Screw, .562-18 hx shackle Generac Magnum Light Tower

Your Price: $7.89

Click For Price and Specs

60504

60504 Nut, .562-18 hx shackle lock Generac Magnum Light Tower

Your Price: $6.63

Click For Price and Specs

60659

60659 Screw, .500-13x5.000 std hex G5 Generac Magnum Light Tower

Your Price: $6.63

Click For Price and Specs

60674

60674 Stud, wheel - .500-20, G8 Generac Magnum Light Tower

Your Price: $11.31

Click For Price and Specs

60698

60698 Washer, .375 flat .875/.040 18-8 ss Generac Magnum Light Tower

Your Price: $8.97

Click For Price and Specs

60831

60831 Screw, .375-16x1.500 std hex 18-8 ss Generac Magnum Light Tower

Your Price: $1.59

Click For Price and Specs

62221

62221 (60307) Nut, .500-13 nylock, G5 Generac Magnum Light Tower

Your Price: $7.35

Click For Price and Specs

A0000414753

A0000414753 (12207) Axle 3500LB 56SC 68.5TC Generac Magnum Light Tower

Your Price: $529.00

Click For Price and Specs
