Stone 1285PM Gearcase Assembly

  • Hover over the parts to see the part number
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part



Gearcase Assembly
ST27010 3296-23 (ST80051) 26325 3296-39 (ST80056) 325-6 (ST80075) 3256-26 (ST80343) 3256-26 (ST80343) Check Options Below Check Options Below Check Options Below ST46108 ST34096 322-3 (ST80159) 3253-4 (ST80086) ST44332 ST46108 ST32253 ST42461-2 ST80002 ST28084 ST46107 3253-6 (ST80335) 80248 ST46062 ST46064 ST47180 ST28181 3257-14 (ST80097) ST28094 ST28093 ST30401 (30089) 3253-3 (ST80116) 321-6 (ST80354) ST80508 3253-4 (ST80086) Check Options Below ST44284 ST28087-03 (ST28087) ST28092 ST35295 ST34765 ST22099-03 (ST22099-2) 3257-14 (ST80097) 3253-21 (ST80058) 323-8 (ST80176) ST28085 ST28088 ST28088 ST32177 ST28098 ST32101 ST32101 ST32101 ST28095 ST32213 ST80098 ST80098 ST28097 ST81060 Check Options Below 3253-4 (ST80086) ST41039 (ST80090) ST29469 ST80520 ST81060 3296-53 (ST80082) ST26326 325-6 (ST80075) Check Options Below

2412-98

2412-98 (ST34492) Clamp Hose B&S for Toro/Stone Mixers

Your Price: $1.87

Click For Price and Specs

321-6

321-6 (ST80354) HHCS 1/4-20 x 1.00 ZN for Toro/Stone Mixers

Your Price: $1.38

Click For Price and Specs

322-3

322-3 (ST80159) HHCS 5/16-18 X 3/4 ZN for Toro/Stone Mixers

Your Price: $1.65

Click For Price and Specs

323-10

323-10 (ST80178) Screw HHCS-GR5 for Toro/Stone Mixers

Your Price: $1.59

Click For Price and Specs

323-7

323-7 (ST80145) Screw HHCS-GR5 for Toro/Stone Mixers

Your Price: $6.36

Click For Price and Specs

323-8

323-8 (ST80176) Screw HHCS for Toro/Stone Mixers

Your Price: $6.99

Click For Price and Specs

325-5

325-5 (ST80104) Screw HHCS for Toro/Stone Mixers

Your Price: $1.90

Click For Price and Specs

325-6

325-6 (ST80075) HHCS 1/2-13x1-1/2 ZN for Toro/Stone Mixers

Your Price: $7.17

Click For Price and Specs

3253-21

3253-21 (ST80058) WSHRL 3/8 Med Split ZN for Toro/Stone Mixers

Your Price: $1.16

Click For Price and Specs

ST80116

3253-3 (ST80116) WSHRL 1/4 Med Split ZN Toro/Stone 1285PM 1650PM Mortar Mixers

Click For Price and Specs

3253-4

3253-4 (ST80086) WSHRL 5/16 Med Split ZN for Toro/Stone Mixers

Your Price: $1.60

Click For Price and Specs

ST80335

3253-6 (ST80335) WSHRL 7/16 Med Split for Toro/Stone Mixers

Click For Price and Specs

3256-26

3256-26 (ST80343) Washer, Flat for Toro/Stone Mixers

Your Price: $1.42

Click For Price and Specs

3257-14

3257-14 (ST80097) Key Woodruff for Toro/Stone Mixers

Your Price: $12.84

Click For Price and Specs

3296-23

3296-23 (ST80051) Nut NY for Toro/Stone Mixers

Your Price: $1.73

Click For Price and Specs

3296-29

3296-29 (ST80114) Nut NY for Toro/Stone Mixers

Your Price: $2.73

Click For Price and Specs

ST80056

3296-39 (ST80056) Nut NY Toro/Stone Mixers

Click For Price and Specs

3296-53

3296-53 (ST80082) NUTNY 5/8-11 ZN Toro/Stone 1050PM 1265PM 1285PM 1650PM Mixers

Your Price: $2.67

Click For Price and Specs

5-7280

5-7280 (ST80100) Key Square for Toro/Stone Mixers

Your Price: $10.80

Click For Price and Specs

ST22075

ST22075 (ST22075-03) Gearcase Assembly Toro/Stone 1285PM 1650PM Mortar Mixer

Your Price: $2,842.75

Click For Price and Specs

ST22099-03

ST22099-03 (ST22099-2) Handle Clutch for Toro/Stone Mixers

Your Price: $206.07

Click For Price and Specs

ST22808

ST22808 Kit Gas Tank B&S for Toro/Stone Mixers

Click For Price and Specs

ST26326

ST26326 Washer, Flat for Toro/Stone Mixers

Your Price: $2.99

Click For Price and Specs

ST27010

ST27010 Gasket Adapter Engine for Toro/Stone Mixers

Your Price: $10.86

Click For Price and Specs

ST27795

ST27795 Key Clutch Adapter Honda/B&S/11.5 hp Robin for Toro/Stone Mixers

Your Price: $16.78

Click For Price and Specs

ST27796

ST27796 Bushing Clutch Adapter Honda/B&S/11.5 hp Robin for Toro/Stone Mixers

Click For Price and Specs

ST28084

ST28084 Gearcase for Toro/Stone Mixers

Your Price: $1,873.48

Click For Price and Specs

ST28085

ST28085 Cover Gearcase for Toro/Stone Mixers

Your Price: $616.47

Click For Price and Specs

ST28087-03

ST28087-03 (ST28087) Coupling Shaft for Toro/Stone Mixers

Your Price: $163.82

Click For Price and Specs

ST28088

ST28088 Gasket Gearcase for Toro/Stone Mixers

Your Price: $24.18

Click For Price and Specs

ST28092

ST28092 Shaft Output GB for Toro/Stone Mixers

Your Price: $447.14

Click For Price and Specs

ST28093

ST28093 Clutch Fork for Toro/Stone Mixers

Your Price: $191.07

Click For Price and Specs

ST28094

ST28094 Shaft Clutch for Toro/Stone Mixers

Your Price: $149.77

Click For Price and Specs

ST28095

ST28095 Input Shaft & Pinion for Toro/Stone Mixers

Your Price: $317.92

Click For Price and Specs

ST28096

ST28096 Gear Internal for Toro/Stone Mixers

Your Price: $528.40

Click For Price and Specs

ST28097

ST28097 Pinion Output for Toro/Stone Mixers

Your Price: $296.27

Click For Price and Specs

ST28098

ST28098 Gear Output for Toro/Stone Mixers

Your Price: $552.54

Click For Price and Specs

ST28181

ST28181 Spacer Clutch Fork for Toro/Stone Mixers

Your Price: $16.08

Click For Price and Specs

ST28193-2

ST28193-2 Base Motor Electric for Toro/Stone Mixers

Click For Price and Specs

ST28202

ST28202 Adapter B&S for Toro/Stone Mixers

Click For Price and Specs

ST28210

ST28210 Motor 5hp Electric 1-Phase for Toro/Stone Mixers

Click For Price and Specs

ST28211

ST28211 Motor 5hp Electric 3-Phase for Toro/Stone Mixers

Click For Price and Specs

ST28267

ST28267 Bushing Shaft B&S for Toro/Stone Mixers

Click For Price and Specs

ST28375-2

ST28375-2 Base Motor Top B&S for Toro/Stone Mixers

Click For Price and Specs

ST28376-2

ST28376-2 Base Motor Bottom B&S for Toro/Stone Mixers

Your Price: $92.37

Click For Price and Specs

ST28398

ST28398 Adapter Honda/11.5 hp Robin for Toro/Stone Mixers

Your Price: $503.19

Click For Price and Specs

ST28399-2

ST28399-2 Base Motor Honda for Toro/Stone Mixers

Click For Price and Specs

ST28844

ST28844 Bushing Shaft Honda for Toro/Stone Mixers

Your Price: $54.34

Click For Price and Specs

ST29469

ST29469 SHCS Mod 3/8-16x1 (Honda/11.5hp Robin) for Toro/Stone Mixers

Your Price: $17.38

Click For Price and Specs

ST29809

ST29809 Engine 11hp Honda for Toro/Stone Mixers

Your Price: $3,336.92

Click For Price and Specs

ST30401

ST30401 (30089) Clutch Gearbox for Toro/Stone Mixers

Your Price: $1,055.71

Click For Price and Specs

ST32101

ST32101 Roller Bearing for Toro/Stone Mixers

Your Price: $200.62

Click For Price and Specs

ST32177

ST32177 Bearing Ball for Toro/Stone Mixers

Your Price: $86.15

Click For Price and Specs

ST32179

ST32179 Oil Seal Honda/B&S for Toro/Stone Mixers

Your Price: $32.24

Click For Price and Specs

ST32213

ST32213 Bearing for Toro/Stone Mixers

Your Price: $51.22

Click For Price and Specs

ST32253

ST32253 Gasket Access Cover for Toro/Stone Mixers

Your Price: $22.48

Click For Price and Specs

ST32342

ST32342 Engine 11.5hp Robin for Toro/Stone Mixers

Click For Price and Specs

ST34051

ST34051 Cast Iron Sheave for Toro/Stone Mixers

Your Price: $149.77

Click For Price and Specs

ST34096

ST34096 Oil Sight Plug for Toro/Stone Mixers

Your Price: $47.74

Click For Price and Specs

ST34765

ST34765 Flex Grip for Toro/Stone Mixers

Your Price: $6.81

Click For Price and Specs

ST34783

ST34783 Throttle B&S for Toro/Stone Mixers

Your Price: $112.51

Click For Price and Specs

ST35295

ST35295 Seal Output Shaft for Toro/Stone Mixers

Your Price: $75.26

Click For Price and Specs

ST35321

ST35321 Battery B&S for Toro/Stone Mixers

Click For Price and Specs

ST36068

ST36068 Starter Manual 3 Phase for Toro/Stone Mixers

Click For Price and Specs

ST38114

ST38114 Cable Battery 15" Blk 18hp B&S for Toro/Stone Mixers

Your Price: $37.24

Click For Price and Specs

ST38121

ST38121 Spring Governor for Toro/Stone Mixers

Your Price: $19.63

Click For Price and Specs

ST38507

ST38507 Oil Seal 11.5 hp Robin for Toro/Stone Mixers

Your Price: $35.02

Click For Price and Specs

ST39433

ST39433 (ST80099) Ring Retaining for Toro/Stone Mixers

Your Price: $2.08

Click For Price and Specs

ST41039

ST41039 (ST80090) Stud 7/16-14x1-7/8 for Toro/Stone Mixers

Your Price: $40.30

Click For Price and Specs

ST42461-2

ST42461-03 (ST42461-2) Cover Clutch Access for Toro/Stone Mixers

Click For Price and Specs

ST42672-2

ST42672-2 Box Battery B&S for Toro/Stone Mixers

Click For Price and Specs

ST42673

ST42673 Bracket Hold Down 18hp B&S for Toro/Stone Mixers

Click For Price and Specs

ST44284

ST44284 (ST44284-03) Spacer Drum Shaft TPE for Toro/Stone Mixers

Click For Price and Specs

ST44286

ST44286 (ST28374) Spacer Motor Base B&S for Toro/Stone Mixers

Your Price: $8.91

Click For Price and Specs

ST44332

ST44332 Plug 7/8-14 O-Ring for Toro/Stone Mixers

Your Price: $14.52

Click For Price and Specs

ST46059

ST46059 Cap Fuel B&S for Toro/Stone Mixers

Your Price: $75.79

Click For Price and Specs

ST46062

ST46062 Connection Elbow for Toro/Stone Mixers

Your Price: $27.22

Click For Price and Specs

ST46064

ST46064 Breather for Toro/Stone Mixers

Your Price: $13.15

Click For Price and Specs

ST46107

ST46107 Pipe Plug 1/2 NPT SQ HD for Toro/Stone Mixers

Your Price: $2.29

Click For Price and Specs

ST46108

ST46108 Magnetic Plug 1/2 IN for Toro/Stone Mixers

Your Price: $23.22

Click For Price and Specs

ST47180

ST47180 O-Ring for Toro/Stone Mixers

Your Price: $1.47

Click For Price and Specs

ST47244

ST47244 Rubber 1.5x6.75 B&S for Toro/Stone Mixers

Your Price: $17.10

Click For Price and Specs

ST48284

ST48284 Cable Battery 25" Red 18hp B&S for Toro/Stone Mixers

Click For Price and Specs

ST80002

ST80002 PINDL 1/4 X 5/8 for Toro/Stone Mixers

Click For Price and Specs

ST80098

ST80098 Ring Retaining for Toro/Stone Mixers

Your Price: $1.66

Click For Price and Specs

ST80103

ST80103 Stud 7/16-14x2-3/4 (18 B&S 0nly) for Toro/Stone Mixers

Click For Price and Specs

ST80169

ST80169 HHCS 5/16 - 18 x 2 ZN GR5 for Toro/Stone Mixers

Your Price: $4.39

Click For Price and Specs

ST80439

ST80439 SHCS 5/16 - 18 X 1 ZN for Toro/Stone Mixers

Click For Price and Specs

ST80508

ST80508 HHBT 5/16 - 18 X 7/8 DG PT ZN for Toro/Stone Mixers

Click For Price and Specs

ST80520

ST80520 HHCS 5/8 - 11 X 4 - 1/2 ZN Shear Bolt for Toro/Stone Mixers

Your Price: $8.58

Click For Price and Specs

ST80607

ST80607 SHCS 5/16 - 18 X 2 ZN for Toro/Stone Mixers

Click For Price and Specs

ST81060

ST81060 Key Square for Toro/Stone Mixers

Your Price: $2.20

Click For Price and Specs
