Genie GS-4047 Steer Linkage and Wheels

Hover over the part on the breakdown below and click to see details
Click the red arrows to navigate to the next area of the machine
All parts shown are listed below the photo
Clicking on the part will take you to the part

105454GT WHEEL & TIRE ASSEMBLY LP 15" Genie GS-4047 Scissor Lift

Your Price: $308.17

Click For Price and Specs

1251997GT NUT TOPLOCK FLANGE 1/2-13 Genie GS-4047 Scissor Lift

Your Price: $2.39

Click For Price and Specs

1256109GT SCREW HHC 3/8-16X.75 GR8 Genie GS-4047 Scissor Lift

Your Price: $1.81

Click For Price and Specs

1256123GT SCREW HHC 1/4-20X3.25 GR8 Genie GS-4047 Scissor Lift

Your Price: $2.58

Click For Price and Specs

1256287GT SCREW HHC 1/2-13X3.5 GR8 Genie GS-4047 Scissor Lift

Your Price: $12.03

Click For Price and Specs

1259193GT CLEVIS PIN 3/4 X 2" Genie GS-4047 Scissor Lift

Your Price: $12.87

Click For Price and Specs

1259195GT PIN CLEVIS 3/4" X 3.25" Genie GS-4047 Scissor Lift

Your Price: $10.23

Click For Price and Specs

13635-10GT COTTER PIN .156 X 1.75" Genie GS-4047 Scissor Lift

Your Price: $1.18

Click For Price and Specs

18722GT BEARING 2.25" ID X 2.50" OD X 1.50 L Genie GS-4047 Scissor Lift

Your Price: $21.20

Click For Price and Specs

21253GT HAIR PIN .125 X 2" Genie GS-4047 Scissor Lift

Your Price: $1.56

Click For Price and Specs

230364GT FORMING HOSE CLAMP SUPPORT Genie GS-4047 Scissor Lift

Your Price: $82.95

Click For Price and Specs

44780GT NUT CASTLE 1.125-18 UNEF Genie GS-4047 Scissor Lift

Your Price: $22.25

Click For Price and Specs

44781GT KEY RECTANGULAR .31X.28X1.25" Genie GS-4047 Scissor Lift

Your Price: $12.12

Click For Price and Specs

47946GT BEARING 1" ID X 1.25" OD X .49 L Genie GS-4047 Scissor Lift

Your Price: $9.21

Click For Price and Specs

58592GT PLATE HOSE ROUTING BULKHEAD Genie GS-4047 Scissor Lift

Your Price: $21.28

Click For Price and Specs

66770GT STRAIGHT DRIVE-IN ZERK FITTING Genie GS-4047 Scissor Lift

Your Price: $2.40

Click For Price and Specs

78736GT CLAMP 2-HOSE PLASTIC Genie GS-4047 Scissor Lift

Your Price: $2.23

Click For Price and Specs

824027GT NUT TOPLOCK FLANGE 1/4-20 G Genie GS-4047 Scissor Lift

Your Price: $1.28

Click For Price and Specs

824120GT FLAT WASHER .375 X 1.50 X .125 Genie GS-4047 Scissor Lift

Your Price: $1.82

Click For Price and Specs

824124GT CARRIAGE BOLT 1/4-20 X .75 GR5 Genie GS-4047 Scissor Lift

Your Price: $2.42

Click For Price and Specs

8255GT SCREW HHC 3/8-16 X .75 Genie GS-4047 Scissor Lift

Your Price: $1.42

Click For Price and Specs

96572GT STEER YOKE RIGHT GROUND CONTROL SIDE Genie GS-4047 Scissor Lift

Your Price: $801.94

Click For Price and Specs

96573GT STEER YOKE LEFT BATTERY PACK SIDE Genie GS-4047 Scissor Lift

Your Price: $801.94

Click For Price and Specs

96574GT TIE ROD Genie GS-4047 Scissor Lift

Your Price: $269.78

Click For Price and Specs

97267GT TIE ROD ASSEMBLY BATTERY PACK SIDE Genie GS-4047 Scissor Lift

Your Price: $380.00

Click For Price and Specs
