Barreto 825TKL Lift Arm Assembly


  • Hover over the part on the breakdown below and click to see details
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part




00564C

00564C TOOL MOUNT ASSEMBLY Barreto 825TKL Mini Track Loader

Click For Price and Specs

03552

03552 LOCK PIN PL6-2500 Barreto 825TKL Mini Track Loader

Your Price: $93.19

Click For Price and Specs

05044

05044 GREASE ZERK 1/4-28 UNF Barreto 825TKL Mini Track Loader

Your Price: $8.40

Click For Price and Specs

5057

05057 HH CAP SCREW 3/8-16 NC X 3/4 G5 ZINC Barreto 825TKL Mini Track Loader

Click For Price and Specs

05073

05073 NUT NYLOCK 3/8-16 NC ZINC Barreto 825TKL Mini Track Loader

Your Price: $1.94

Click For Price and Specs

05083

05083 WASHER 7/16 USS ZINC Barreto 825TKL Mini Track Loader

Your Price: $1.46

Click For Price and Specs

05096

05096 NUT NYLOCK 1/4-20 NC ZINC Barreto 825TKL Mini Track Loader

Your Price: $1.46

Click For Price and Specs

05101

05101 WASHER 3/8 SAE ZINC Barreto 825TKL Mini Track Loader

Your Price: $1.46

Click For Price and Specs

05131

05131 HHFS 5/16-18 X 3/4 G8 ZN Barreto 825TKL Mini Track Loader

Your Price: $8.97

Click For Price and Specs

5177

05177 HH CAP SCREW 7/16-20 NF X 2-1/4 G5 ZINC Barreto 825TKL Mini Track Loader

Click For Price and Specs

5262

05262 HH CAP SCREW 3/8-16 NC X 2 G5 ZINC Barreto 825TKL Mini Track Loader

Click For Price and Specs

05273

05273 NUT NYLOCK 5/16-18 NC ZINC Barreto 825TKL Mini Track Loader

Your Price: $1.46

Click For Price and Specs

05404

05404 HHFS 1/4-20 X 1 G5 ZN Barreto 825TKL Mini Track Loader

Your Price: $2.46

Click For Price and Specs

5540

05540 WASHER 3/8 FENDER ZINC Barreto 825TKL Mini Track Loader

Click For Price and Specs

05563

05563 FSCS 5/16 NC X 1/2 ZN Barreto 825TKL Mini Track Loader

Your Price: $2.39

Click For Price and Specs

05566

05566 HH CAP SCREW 5/16-18 NC X 2 G5 ZINC Barreto 825TKL Mini Track Loader

Your Price: $9.03

Click For Price and Specs

10626

10626 PIVOT PIN WASHER Barreto 825TKL Mini Track Loader

Your Price: $1.97

Click For Price and Specs

10703

10703 BUSHING CONNEX 1.5X1.25X1 Barreto 825TKL Mini Track Loader

Your Price: $44.12

Click For Price and Specs

11983

11983 TUBE CLAMP 5/8" Barreto 825TKL Mini Track Loader

Your Price: $46.92

Click For Price and Specs

12962 R1

12962 R1 LIFT ARM Barreto 825TKL Mini Track Loader

Click For Price and Specs

12963X16

12963X16 LIFT CYLINDER 2.0 X 16 Barreto 825TKL Mini Track Loader

Click For Price and Specs

12964-X10

12964-X10 TILT CYLINDER 2.50 X 10 Barreto 825TKL Mini Track Loader

Your Price: $621.21

Click For Price and Specs

12967

12967 HINGE PIN CYLINDER-LIFT ARM Barreto 825TKL Mini Track Loader

Your Price: $39.92

Click For Price and Specs

12970-G

12970-G HINGE PIN FRAME-LIFT ARM Barreto 825TKL Mini Track Loader

Your Price: $42.68

Click For Price and Specs

13130

13130 BUTTON BUMPER E-4270 3/4 X 3/16 Barreto 825TKL Mini Track Loader

Your Price: $2.83

Click For Price and Specs

13141

13141 BOLT SLEEVE LEVEL INDICATOR Barreto 825TKL Mini Track Loader

Click For Price and Specs

13142

13142 LEVEL INDICATOR GUIDE Barreto 825TKL Mini Track Loader

Click For Price and Specs

13144

13144 ATTACHMENT LEVEL INDICATOR Barreto 825TKL Mini Track Loader

Click For Price and Specs

13170 R1

13170 R1 CYLINDER CLAMP LEVEL INDICATOR Barreto 825TKL Mini Track Loader

Click For Price and Specs

13211

13211 LIFT LOCK Barreto 825TKL Mini Track Loader

Your Price: $87.31

Click For Price and Specs

13268-.46

13268-.46 ARM SHIM INNER Barreto 825TKL Mini Track Loader

Click For Price and Specs

13268-.75

13268-.75 ARM SHIM INNER Barreto 825TKL Mini Track Loader

Click For Price and Specs

13275

13275 ARM SPACER OUTER Barreto 825TKL Mini Track Loader

Your Price: $12.33

Click For Price and Specs

13337

13337 QUICK DISCONNECT FEMALE Barreto 825TKL Mini Track Loader

Your Price: $143.10

Click For Price and Specs

13338

13338 QUICK DISCONNECT MALE Barreto 825TKL Mini Track Loader

Click For Price and Specs

13342

13342 FITTING BULKHEAD 2706LN-08-10 Barreto 825TKL Mini Track Loader

Click For Price and Specs

13344

13344 FITTING BULKHEAD 2706LN-08-08 Barreto 825TKL Mini Track Loader

Click For Price and Specs

14307

14307 TUBE CLAMP .50" Barreto 825TKL Mini Track Loader

Click For Price and Specs

14308

14308 QUAD CLAMP CAP Barreto 825TKL Mini Track Loader

Click For Price and Specs

14324

14324 SPHERICAL EYE 1.25 Barreto 825TKL Mini Track Loader

Your Price: $27.72

Click For Price and Specs

14325

14325 HOSE TILT UPPER END 3/8" Barreto 825TKL Mini Track Loader

Click For Price and Specs

14326

14326 HOSE LOWER TILT 3/8" Barreto 825TKL Mini Track Loader

Click For Price and Specs

14327

14327 HYDRAULIC LINE AUX 1 BOTTOM Barreto 825TKL Mini Track Loader

Your Price: $96.76

Click For Price and Specs

14329

14329 HYDRAULIC LINE AUX 1 TOP Barreto 825TKL Mini Track Loader

Your Price: $91.16

Click For Price and Specs

14330

14330 HYDRAULIC LINE TILT LOWER 3/8" Barreto 825TKL Mini Track Loader

Click For Price and Specs

14330AX1

14330AX1 HYDRAULIC LINE AUX 2 LINE 1 Barreto 825TKL Mini Track Loader

Your Price: $75.23

Click For Price and Specs

14330AX2

14330AX2 HYDRAULIC LINE AUX 2 LINE 2 Barreto 825TKL Mini Track Loader

Your Price: $80.71

Click For Price and Specs

14349

14349 TUBE PAD Barreto 825TKL Mini Track Loader

Click For Price and Specs
