Bomag BT65/4 Spring and Guide Unit

  • Hover over the part on the breakdown below and click to see details
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part





05551490

05551490 Hose clip Bomag BT65-4 Tamper

Click For Price and Specs

05973134

05973134 Oil level gauge Bomag BT65-4 Tamper

Click For Price and Specs

06221008

06221008 Loop ring Bomag BT65-4 Tamper

Click For Price and Specs

06221040

06221040 Loop ring Bomag BT65-4 Tamper

Click For Price and Specs

06221202

06221202 Loop ring Bomag BT65-4 Tamper

Click For Price and Specs

06245030

06245030 Piston guiding ring Bomag BT65-4 Tamper

Click For Price and Specs

07131621

07131621 Hexagon bolt Bomag BT65-4 Tamper

Click For Price and Specs

07140834

07140834 Hexagon bolt Bomag BT65-4 Tamper

Click For Price and Specs

07230827

07230827 Socket-head cap screw Bomag BT65-4 Tamper

Click For Price and Specs

07621416

07621416 Screw plug Bomag BT65-4 Tamper

Click For Price and Specs

07632015

07632015 Screw plug Bomag BT65-4 Tamper

Click For Price and Specs

08511730

08511730 Washer Bomag BT65-4 Tamper

Click For Price and Specs

08752084

08752084 Spring washer Bomag BT65-4 Tamper

Click For Price and Specs

09331128

09331128 Sealing ring Bomag BT65-4 Tamper

Click For Price and Specs

09331746

09331746 Sealing ring Bomag BT65-4 Tamper

Click For Price and Specs

54020402

54020402 Floating wrist pin Bomag BT65-4 Tamper

Click For Price and Specs

54210111

54210111 Piston rod Bomag BT65-4 Tamper

Click For Price and Specs

54210123

54210123 Piston Bomag BT65-4 Tamper

Click For Price and Specs

54210135

54210135 Pressure spring Bomag BT65-4 Tamper

Click For Price and Specs

54210142

54210142 Plate Bomag BT65-4 Tamper

Click For Price and Specs

54210164

54210164 Inner guide Bomag BT65-4 Tamper

Click For Price and Specs

54210170

54210170 Outer guide Bomag BT65-4 Tamper

Click For Price and Specs

54210181

54210181 Foot cup Bomag BT65-4 Tamper

Click For Price and Specs

54210244

54210244 Cover plate Bomag BT65-4 Tamper

Click For Price and Specs

54210252

54210252 (54020501) Bellows Bomag BT65-4 Tamper

Click For Price and Specs

54210141

54210262 (54210141) Stop Bomag BT65-4 Tamper

Click For Price and Specs
