Barreto 1320H/1620B Tine Shaft and Cover Assembly

  • Hover over the part on the breakdown below and click to see details
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part





01008

01008 TINE COVER 1320-1620 Barreto 1320H-1620B Tiller

Your Price: $449.77

Click For Price and Specs

01011

01011 Tine Shaft Round Barreto 1320 1620 Tillers

Your Price: $363.87

Click For Price and Specs

01012

01012 DEPTH BAR Barreto 1320H-1620B Tiller

Your Price: $149.27

Click For Price and Specs

01018

01018 PIN Barreto 1320H-1620B Tiller

Your Price: $47.38

Click For Price and Specs

01099

01099 HANDLE DEPTH BAR Barreto 1320H-1620B Tiller

Click For Price and Specs

02065

02065 MANIFOLD TINE MOTOR Barreto 1320H-1620B Tiller

Your Price: $103.90

Click For Price and Specs

03001

03001 O-RING 2-152 3-7/16 OD X 3/32 SECTION Barreto 1320H-1620B Tiller

Your Price: $14.01

Click For Price and Specs

03018

03018 GRIP 1/8 X 3/4 X 2-3/4 Barreto 1320H-1620B Tiller

Your Price: $12.72

Click For Price and Specs

03040-01

03040-01 DECAL MADE IN USA Barreto 1320H-1620B Tiller

Your Price: $9.78

Click For Price and Specs

03040-02

03040-02 DECAL BARRETO 3-1/2 X 11-1/4 Barreto 1320H-1620B Tiller

Your Price: $16.33

Click For Price and Specs

03040-03

03040-03 DECAL CAUTION BLACK & WHITE Barreto 1320H-1620B Tiller

Your Price: $14.03

Click For Price and Specs

03040-04

03040-04 DECAL GREASE DAILY Barreto 1320H-1620B Tiller

Your Price: $9.78

Click For Price and Specs

03040-07

03040-07 DECAL CAUTION YELLOW Barreto 1320H-1620B Tiller

Your Price: $12.85

Click For Price and Specs

03040-08

03040-08 DECAL WARNING YELLOW Barreto 1320H-1620B Tiller

Your Price: $12.85

Click For Price and Specs

03040-11

03040-11 DECAL BARRETO 2-3/16 X 7-3/8 Barreto 1320H-1620B Tiller

Your Price: $23.45

Click For Price and Specs

03040-59

03040-59 DECAL REPLACEMENT TINE PN Barreto 1320H-1620B Tiller

Your Price: $12.60

Click For Price and Specs

03065

03065 HAIR SPRING COTTER #4 Barreto 1320H-1620B Tiller

Your Price: $1.94

Click For Price and Specs

03080

03080 SPRING Barreto 1320H-1620B Tiller

Your Price: $20.52

Click For Price and Specs

03196 R1

03196 R1 TINE REVERSIBLE Barreto 1320H-1620B Tiller

Your Price: $27.70

Click For Price and Specs

03196 R1-12

03196 R1-12 Reversible Tine SET OF 12 Barreto 1320H-1620B Tiller

Your Price: $233.25

Click For Price and Specs

03302

03302 FITTING 6409-6 PLUG Barreto 1320H-1620B Tiller

Your Price: $20.18

Click For Price and Specs

03341-22

03341-22 DECAL TILLER OPERATING INSTRUCTIONS Barreto 1320H-1620B Tiller

Your Price: $22.90

Click For Price and Specs

03341-23

03341-23 DECAL TILLER SAFETY INSTRUCTIONS Barreto 1320H-1620B Tiller

Your Price: $22.92

Click For Price and Specs

03930

03930 SEAL CR 19763 Barreto 1320H-1620B Tiller

Your Price: $28.04

Click For Price and Specs

03943

03943 BALL BEARING SKF 6208 Barreto 1320H-1620B Tiller

Your Price: $52.46

Click For Price and Specs

04520

04520 FITTING 6400-8-8 Barreto 1320H-1620B Tiller

Your Price: $14.01

Click For Price and Specs

04605-F

04605-F TINE MOTOR Barreto 1320H-1620B Tiller

Your Price: $807.21

Click For Price and Specs

05006

05006 ROLL PIN SLOTTED SPRING 3/8 X 1-1/2 ZINC Barreto 1320H-1620B Tiller

Your Price: $2.86

Click For Price and Specs

05044

05044 GREASE ZERK 1/4-28 UNF Barreto 1320H-1620B Tiller

Your Price: $8.40

Click For Price and Specs

05056

05056 HH CAP SCREW 3/8-24 NF X 1 G5 ZINC Barreto 1320H-1620B Tiller

Your Price: $1.94

Click For Price and Specs

05059

05059 HH CAP CREW 3/8-16 NC X 1 G5 ZINC Barreto 1320H-1620B Tiller

Your Price: $1.94

Click For Price and Specs

05061

05061 HH CAP SCREW 7/16-20 NF X 1 G8 ZINC Barreto 1320H-1620B Tiller

Your Price: $2.51

Click For Price and Specs

05072

05072 NUT NYLOCK 3/8-24 NF ZINC Barreto 1320H-1620B Tiller

Your Price: $1.46

Click For Price and Specs

05073

05073 NUT NYLOCK 3/8-16 NC ZINC Barreto 1320H-1620B Tiller

Your Price: $1.94

Click For Price and Specs

05074

05074 NUT 7/16-20 NF G8 ZINC Barreto 1320H-1620B Tiller

Your Price: $1.46

Click For Price and Specs

05083

05083 WASHER 7/16 USS ZINC Barreto 1320H-1620B Tiller

Your Price: $1.46

Click For Price and Specs

05092

05092 HH CAP SCREW 3/8-16 NC X 1-1/2 G5 ZINC Barreto 1320H-1620B Tiller

Your Price: $1.94

Click For Price and Specs

05103

05103 WASHER 3/8 A325 HARDENED ZINC Barreto 1320H-1620B Tiller

Your Price: $1.46

Click For Price and Specs

05140

05140 WHIZ-LOCK 5/16-18 X 3/4 Barreto 1320H-1620B Tiller

Your Price: $6.00

Click For Price and Specs

05204

05204 PIPE COUPLER 1/8" Barreto 1320H-1620B Tiller

Your Price: $9.18

Click For Price and Specs

05256

05256 GREASE ZERK 1/8 NPT Barreto 1320H-1620B Tiller

Your Price: $2.62

Click For Price and Specs

05273

05273 NUT NYLOCK 5/16-18 NC ZINC Barreto 1320H-1620B Tiller

Your Price: $1.46

Click For Price and Specs

05282

05282 PIPE NIPPLE 1/8" X 5 LONG Barreto 1320H-1620B Tiller

Your Price: $17.35

Click For Price and Specs

05361

05361 SH CAP SCREW 5/16-18 NC X 7/8 ZINC Barreto 1320H-1620B Tiller

Your Price: $2.58

Click For Price and Specs

05585

05585 SH CAP SCREW 1/2-13 NC X 1-1/4 ZINC Barreto 1320H-1620B Tiller

Your Price: $2.78

Click For Price and Specs

05603

05603 SNAP RING HO-315 3-5/32 INTERNAL Barreto 1320H-1620B Tiller

Your Price: $14.01

Click For Price and Specs

05607

05607 SNAP RING SH-156 1-9/16" EXTERNAL Barreto 1320H-1620B Tiller

Your Price: $9.36

Click For Price and Specs

10144

10144 OUTBOARD BEARING ASSEMBLY Barreto 1320H-1620B Tiller

Your Price: $144.18

Click For Price and Specs

10538

10538 RH SIDE PLATE TINE SECTION Barreto 1320H-1620B Tiller

Click For Price and Specs

11278

11278 TINE MOTOR HUB SPLINED Barreto 1320H-1620B Tiller

Your Price: $149.27

Click For Price and Specs

12423

12423 TINE SHAFT SPLINED Barreto 1320H-1620B Tiller

Your Price: $432.64

Click For Price and Specs

12424

12424 TINE SIDE PLATE LEFT Barreto 1320H-1620B Tiller

Your Price: $265.05

Click For Price and Specs
