Barreto 1324D/1624D Cylinder Assembly

  • Hover over the part on the breakdown below and click to see details
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part





02612

02612 PISTON Barreto 1324D-1624D Wheeled Trencher

Your Price: $134.93

Click For Price and Specs

02613

02613 CYLINDER END Barreto 1324D-1624D Wheeled Trencher

Your Price: $167.05

Click For Price and Specs

02700

02700 CYLINDER Barreto 1324D-1624D Wheeled Trencher

Your Price: $328.98

Click For Price and Specs

02701

02701 CYLINDER ROD Barreto 1324D-1624D Wheeled Trencher

Your Price: $121.47

Click For Price and Specs

03232

03232 O-RING 2-014 5/8 OD X 1/16 SECTION Barreto 1324D-1624D Wheeled Trencher

Your Price: $2.47

Click For Price and Specs

03234

03234 O-RING 2-228 2-1/2 OD X 1/8 SECTION Barreto 1324D-1624D Wheeled Trencher

Your Price: $2.82

Click For Price and Specs

03236

03236 O-RING 2-330 2-1/2 OF X 3/16 SECTION Barreto 1324D-1624D Wheeled Trencher

Your Price: $2.70

Click For Price and Specs

03237

03237 BACK UP RING 8-330N90 PARBAK Barreto 1324D-1624D Wheeled Trencher

Your Price: $14.67

Click For Price and Specs

03255

03255 WIPER 1 X 1-1/2 X 5/16 J-1000 Barreto 1324D-1624D Wheeled Trencher

Your Price: $17.75

Click For Price and Specs

03259

03259 SEAL 1 X 1/8 X1/8 ROD Barreto 1324D-1624D Wheeled Trencher

Your Price: $22.92

Click For Price and Specs

04514

04514 SEAL KIT CYLINDER Barreto 1324D-1624D Wheeled Trencher

Your Price: $71.84

Click For Price and Specs

05046

05046 NUT GRIPCO 1/2-13 NC G5 ZINC Barreto 1324D-1624D Wheeled Trencher

Your Price: $1.78

Click For Price and Specs

05102

05102 WASHER 1/2 SAE ZINC HARDENED Barreto 1324D-1624D Wheeled Trencher

Your Price: $1.94

Click For Price and Specs

05211

05211 SNAP RING HO-256 2-9/16 INTERNAL ZINC Barreto 1324D-1624D Wheeled Trencher

Your Price: $12.72

Click For Price and Specs
