Barreto 712MTH Body Assembly

  • Hover over the part on the breakdown below and click to see details
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part





00481

00481 UNLOADER ASSEMBLY Barreto 712MTH Wheeled Trencher

Your Price: $398.70

Click For Price and Specs

03009-R2

03009-R2 (03009-R1) HOUR METER WITH FLASH ALERT Barreto 712MTH Wheeled Trencher

Your Price: $144.23

Click For Price and Specs

03040-06

03040-06 DECAL "HYDRAULIC OIL ONLY" Barreto 712MTH Wheeled Trencher

Your Price: $9.96

Click For Price and Specs

03503

03503 SIGHT GAUGE Barreto 712MTH Wheeled Trencher

Your Price: $25.96

Click For Price and Specs

04216

04216 FITTING 4603-8-8 Barreto 712MTH Wheeled Trencher

Your Price: $24.84

Click For Price and Specs

04227

04227 FITTING 4501-12-8 Barreto 712MTH Wheeled Trencher

Your Price: $70.34

Click For Price and Specs

04227B-P

04227B-P FITTING 4501-12-8 TAPPED #6 Barreto 712MTH Wheeled Trencher

Your Price: $66.18

Click For Price and Specs

04555

04555 FITTING 6801-4-4 Barreto 712MTH Wheeled Trencher

Your Price: $21.40

Click For Price and Specs

05008

05008 HOSE CLAMP CTB 27 Barreto 712MTH Wheeled Trencher

Your Price: $14.31

Click For Price and Specs

05046

05046 NUT GRIPCO 1/2-13 NC G5 ZINC Barreto 712MTH Wheeled Trencher

Your Price: $1.79

Click For Price and Specs

05049

05049 WHIZ-LOCK 1/4-20 X 3/4 Barreto 712MTH Wheeled Trencher

Your Price: $2.36

Click For Price and Specs

05051

05051 WHIZ-LOCK 1/4 - 20 X 1/2 Barreto 712MTH Wheeled Trencher

Your Price: $1.96

Click For Price and Specs

05069

05069 WHIZ-LOCK 1/4-20 X 5/8 Barreto 712MTH Wheeled Trencher

Your Price: $1.96

Click For Price and Specs

05096

05096 NUT NYLOCK 1/4-20 NC ZINC Barreto 712MTH Wheeled Trencher

Your Price: $1.47

Click For Price and Specs

05102

05102 WASHER 1/2 SAE ZINC HARDENED Barreto 712MTH Wheeled Trencher

Your Price: $1.96

Click For Price and Specs

05140

05140 WHIZ-LOCK 5/16-18 X 3/4 Barreto 712MTH Wheeled Trencher

Your Price: $6.12

Click For Price and Specs

05154

05154 HH CAP SCREW 1/2-13 NC X 5 G5 ZINC Barreto 712MTH Wheeled Trencher

Your Price: $19.03

Click For Price and Specs

05169

05169 WHIZ-LOCK 5/16-18 X 1/2 Barreto 712MTH Wheeled Trencher

Your Price: $7.20

Click For Price and Specs

05300-01

05300-01 HH CAP SCREW 1/2-13 NC X 1-1/2 G5 ZINC Barreto 712MTH Wheeled Trencher

Your Price: $2.90

Click For Price and Specs

05323

05323 HH CAP SCREW 1/2-13 NC X 1-1/4 G5 ZINC Barreto 712MTH Wheeled Trencher

Your Price: $2.86

Click For Price and Specs

05364

05364 NUT 5/16-18 NC SERRATED FLANGE ZN Barreto 712MTH Wheeled Trencher

Your Price: $1.85

Click For Price and Specs

05419

05419 NUT 1/4-20 NC SERRATED FLANGE ZN Barreto 712MTH Wheeled Trencher

Your Price: $1.96

Click For Price and Specs

05535

05535 WHIZ-LOCK 1/4 - 20 X 7/8 Barreto 712MTH Wheeled Trencher

Your Price: $2.51

Click For Price and Specs

10347

10347 TIRE & RIM 4.10/3.50-4 Barreto 712MTH Wheeled Trencher

Your Price: $138.13

Click For Price and Specs

10347.5

10347.50 BEARING 1/2 BORE Barreto 712MTH Wheeled Trencher

Your Price: $20.78

Click For Price and Specs

10361

10361 FITTING 6409-8 PLUG Barreto 712MTH Wheeled Trencher

Your Price: $11.79

Click For Price and Specs

10526

10526 FITTING 6409-12 PLUG Barreto 712MTH Wheeled Trencher

Your Price: $11.79

Click For Price and Specs

10527

10527 OIL COOLER B & M 70273 11 X 5.75 Barreto 712MTH Wheeled Trencher

Your Price: $432.39

Click For Price and Specs

10958

10958 RUBBER BUSHING Barreto 712MTH Wheeled Trencher

Your Price: $23.43

Click For Price and Specs

11915

11474 FLAP BACKING Barreto 712MTH Wheeled Trencher

Your Price: $71.91

Click For Price and Specs

11475

11475 FLAP Barreto 712MTH Wheeled Trencher

Your Price: $53.84

Click For Price and Specs

11667

11667 FITTING 4604-8-6 Barreto 712MTH Wheeled Trencher

Your Price: $31.08

Click For Price and Specs

11771-M

11771-M FITTING 4606-12-12-12 MACHINED Barreto 712MTH Wheeled Trencher

Your Price: $104.00

Click For Price and Specs

11894 R1

11894 R1 BODY Barreto 712MTH Wheeled Trencher

Your Price: $987.46

Click For Price and Specs

11905

11905 LEVER SPRING Barreto 712MTH Wheeled Trencher

Your Price: $13.38

Click For Price and Specs

11909

11909 WHEEL MOUNT Barreto 712MTH Wheeled Trencher

Click For Price and Specs

11905

11910 R1 LIFT SPACER Barreto 712MTH Wheeled Trencher

Your Price: $13.38

Click For Price and Specs

11914

11914-K (11914) RAISE LEVER Barreto 712MTH Wheeled Trencher

Click For Price and Specs

11915

11915 LIFT STOPS Barreto 712MTH Wheeled Trencher

Your Price: $71.91

Click For Price and Specs

11965

11965 LIFT LINK Barreto 712MTH Wheeled Trencher

Your Price: $21.28

Click For Price and Specs

11970

11970 HOSE PUMP SUCTION 3/4 WIRE HELIX Barreto 712MTH Wheeled Trencher

Your Price: $79.43

Click For Price and Specs

11971

11971 HOSE COOLER OUT / TANK Barreto 712MTH Wheeled Trencher

Your Price: $11.79

Click For Price and Specs

11972

11972 HOSE TANK OUT / COOLER IN 3/4" Barreto 712MTH Wheeled Trencher

Your Price: $31.62

Click For Price and Specs

11974 R1

11974 R1 LIFT BUSHING Barreto 712MTH Wheeled Trencher

Your Price: $7.11

Click For Price and Specs

11975 R1

11975 R1 LIFT BUSHING Barreto 712MTH Wheeled Trencher

Click For Price and Specs

11987

11987 BREATHER HOSE ASSY Barreto 712MTH Wheeled Trencher

Your Price: $37.56

Click For Price and Specs

12090

12090 INSTRUCTION CANISTER Barreto 712MTH Wheeled Trencher

Your Price: $52.42

Click For Price and Specs

12094

12094 ORFICE PLUG .25 Barreto 712MTH Wheeled Trencher

Your Price: $14.48

Click For Price and Specs

12097

12097 SHIELD GUIDE Barreto 712MTH Wheeled Trencher

Your Price: $17.75

Click For Price and Specs

12130

12130 TUBE END CAP 1-1/4" Barreto 712MTH Wheeled Trencher

Your Price: $11.55

Click For Price and Specs

12131

12131 CLAMP 1/2" HOSE CTB-20 Barreto 712MTH Wheeled Trencher

Your Price: $10.26

Click For Price and Specs

12143

12143 CANISTER MOUNT Barreto 712MTH Wheeled Trencher

Your Price: $23.92

Click For Price and Specs

12854

12854 HOSE GUARD Barreto 712MTH Wheeled Trencher

Click For Price and Specs

12981

12981 FENDER WASHER 1/2 X 2 X 1/8 ZN Barreto 712MTH Wheeled Trencher

Your Price: $16.95

Click For Price and Specs
