Barreto 30SG Carriage Right

  • Hover over the part on the breakdown below and click to see details
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part





00335

00335 IDLER ASSEMBLY Barreto 30SG Stump Grinder

Your Price: $279.42

Click For Price and Specs

00366

00366 MID ROLLER ASSY Barreto 30SG Stump Grinder

Your Price: $110.02

Click For Price and Specs

03290

03290 SPACER WASHER .532 X .750 X .125 Barreto 30SG Stump Grinder

Your Price: $8.19

Click For Price and Specs

04029

04029 MOTOR PARKER TF 0240WE080 Barreto 30SG Stump Grinder

Your Price: $1,599.79

Click For Price and Specs

04405

04405 C-BALANCE CARTRIDGE CB10-HV Barreto 30SG Stump Grinder

Your Price: $215.05

Click For Price and Specs

04538

04538 FITTING 6801-6-6 Barreto 30SG Stump Grinder

Your Price: $21.00

Click For Price and Specs

05021

05021 SET SCREW 1/4-20 UNC X 5/16 CUP POINT Barreto 30SG Stump Grinder

Your Price: $1.94

Click For Price and Specs

05039-7

05039-7 CIRCLE COTTER CC-7 Barreto 30SG Stump Grinder

Your Price: $6.84

Click For Price and Specs

05044

05044 GREASE ZERK 1/4-28 UNF Barreto 30SG Stump Grinder

Your Price: $8.40

Click For Price and Specs

05068

05068 WASHER 5/16 SAE ZINC Barreto 30SG Stump Grinder

Your Price: $1.46

Click For Price and Specs

05069

05069 WHIZ LOCK 1/4-20 NC X 5/8 ZINC Barreto 30SG Stump Grinder

Your Price: $1.94

Click For Price and Specs

05078

05078 WASHER 1/4 USS ZINC Barreto 30SG Stump Grinder

Your Price: $1.46

Click For Price and Specs

05084

05084 HEX SOCKET FH CAP SCREW #10-24 X 3/8 Barreto 30SG Stump Grinder

Your Price: $2.15

Click For Price and Specs

05096

05096 NUT NYLOCK 1/4-20 NC ZINC Barreto 30SG Stump Grinder

Your Price: $1.46

Click For Price and Specs

05098

05098 NUT NYLOCK 1/2-13 NC ZINC Barreto 30SG Stump Grinder

Your Price: $1.94

Click For Price and Specs

05099

05099 NUT NYLOCK 5/8-11 NC ZINC Barreto 30SG Stump Grinder

Your Price: $1.49

Click For Price and Specs

05102

05102 WASHER 1/2 SAE ZINC HARDENED Barreto 30SG Stump Grinder

Your Price: $1.94

Click For Price and Specs

05237

05237 HH CAP SCREW 1/4-20 NC X 1 G5 ZINC Barreto 30SG Stump Grinder

Your Price: $1.46

Click For Price and Specs

05250

05250 CLEVIS PIN 1/2 X 2-1/2 ZINC Barreto 30SG Stump Grinder

Your Price: $14.13

Click For Price and Specs

05272

05272 WASHER 5/8 SAE ZINC HARDENED Barreto 30SG Stump Grinder

Your Price: $1.94

Click For Price and Specs

05566

05566 HH CAP SCREW 5/16-18 NC X 2 G5 ZINC Barreto 30SG Stump Grinder

Your Price: $9.03

Click For Price and Specs

05590

05590 HH CAP SCREW 1/2-13 NC X 4 G5 ZINC Barreto 30SG Stump Grinder

Your Price: $6.39

Click For Price and Specs

10272

10272 BUSHING IGUS MFI-1214-12 Barreto 30SG Stump Grinder

Your Price: $15.45

Click For Price and Specs

10707

10707 NUT JAM 5/8-11 NC ZINC Barreto 30SG Stump Grinder

Your Price: $13.03

Click For Price and Specs

10827

10827 WHEEL HUB 1-1/4" TAPERED SOLID Barreto 30SG Stump Grinder

Your Price: $151.42

Click For Price and Specs

10849-R

10849-R RIGHT CARRIAGE Barreto 30SG Stump Grinder

Click For Price and Specs

10876

10876 IDLER ARM Barreto 30SG Stump Grinder

Your Price: $192.33

Click For Price and Specs

10907

10907 ARM ROLLER Barreto 30SG Stump Grinder

Your Price: $71.28

Click For Price and Specs

10908

10908 SPACER Barreto 30SG Stump Grinder

Your Price: $12.72

Click For Price and Specs

10910

10910 ARM SLIDER Barreto 30SG Stump Grinder

Your Price: $43.50

Click For Price and Specs

11144

11144 ROLLER SPACER Barreto 30SG Stump Grinder

Your Price: $22.84

Click For Price and Specs

11156

11156 TENSIONER END Barreto 30SG Stump Grinder

Your Price: $18.28

Click For Price and Specs

11157

11157 WASHER TENSION SPRING Barreto 30SG Stump Grinder

Your Price: $11.82

Click For Price and Specs

11170

11170 TENSIONER STUD Barreto 30SG Stump Grinder

Your Price: $34.70

Click For Price and Specs

11247

11247 ROLLER GUARD Barreto 30SG Stump Grinder

Your Price: $53.74

Click For Price and Specs

11251

11251 ROLLER GUARD MOUNT Barreto 30SG Stump Grinder

Your Price: $47.00

Click For Price and Specs

11447

11447 HH CAP SCREW 1/2-13 NC X 2-1/2 G5 ZN Barreto 30SG Stump Grinder

Your Price: $12.48

Click For Price and Specs

11462-R

11462-R WEIGHT MOUNT RIGHT Barreto 30SG Stump Grinder

Your Price: $201.02

Click For Price and Specs

11470

11470 SPRING GUIDE Barreto 30SG Stump Grinder

Your Price: $15.25

Click For Price and Specs

11474

11474 FLAP BACKING Barreto 30SG Stump Grinder

Your Price: $13.71

Click For Price and Specs

11475

11475 FLAP Barreto 30SG Stump Grinder

Your Price: $52.78

Click For Price and Specs

11490

11490 ROLLER AXLE 5/8 X 4-1/2" Barreto 30SG Stump Grinder

Click For Price and Specs

11674

11674 SPRING CENTURY D-1378 Barreto 30SG Stump Grinder

Your Price: $116.13

Click For Price and Specs

12329

12329 C-BALANCE MANIFOLD SDC10-3S Barreto 30SG Stump Grinder

Your Price: $138.20

Click For Price and Specs

12354

12354 SPROCKET SHIM Barreto 30SG Stump Grinder

Your Price: $22.95

Click For Price and Specs

12367

12367 HOSE FRONT PUMP LEFT / RT MOTOR FRONT Barreto 30SG Stump Grinder

Your Price: $55.04

Click For Price and Specs

12368

12368 HOSE FRONT PUMP RT / RT MOTOR REAR Barreto 30SG Stump Grinder

Your Price: $73.75

Click For Price and Specs
