Generac Magnum MTP6SZ Lift Support Assembly

  • Hover over the part on the breakdown below and click to see details
  • Click the red arrows to navigate to the next area of the machine
  • All parts shown are listed below the photo
  • Clicking on the part will take you to the part





14216

14216 Clamp hose SAE 004 mini Generac Magnum MTP6SZ Trash Pump

Your Price: $3.29

Click For Price and Specs

15627

15627 Clamp tubing .625 heavy duty Generac Magnum MTP6SZ Trash Pump

Your Price: $1.59

Click For Price and Specs

31682B

31682B Tube lift Generac Magnum MTP6SZ Trash Pump

Click For Price and Specs

31686B

31686B Weldment lift support Generac Magnum MTP6SZ Trash Pump

Click For Price and Specs

31688B

31688B Weldment radiator guard RH Generac Magnum MTP6SZ Trash Pump

Click For Price and Specs

31690B

31690B Weldment radiator guard front Generac Magnum MTP6SZ Trash Pump

Click For Price and Specs

36322B

36322B Weldment radiator guard LH Generac Magnum MTP6SZ Trash Pump

Your Price: $348.45

Click For Price and Specs

42775

42775 Screw .625-11 x 4.50 hex G5 Generac Magnum MTP6SZ Trash Pump

Click For Price and Specs

50343

50343 Hose .312ID x .562OD 60PSI Generac Magnum MTP6SZ Trash Pump

Your Price: $3.16

Click For Price and Specs

60195

60195 Rivet .188 dia. x .375 to .500 grip Generac Magnum MTP6SZ Trash Pump

Your Price: $17.53

Click For Price and Specs

60240

60240 Nut .625-11 nylock G5 Generac Magnum MTP6SZ Trash Pump

Your Price: $3.29

Click For Price and Specs

60358

60358 Nut .375-16 nylock G5 Generac Magnum MTP6SZ Trash Pump

Your Price: $15.43

Click For Price and Specs

60376

60376 Screw .500-13 x 4.50 Hex G5 Generac Magnum MTP6SZ Trash Pump

Your Price: $3.29

Click For Price and Specs

60390

60390 Screw .500-13 x 3.50 hex G5 Generac Magnum MTP6SZ Trash Pump

Your Price: $1.59

Click For Price and Specs

62221

62221 Nut .500-13 nylock G5 Generac Magnum MTP6SZ Trash Pump

Your Price: $3.29

Click For Price and Specs

63265

63265 Washer .625 flat 1.312/.07-.13 Generac Magnum MTP6SZ Trash Pump

Your Price: $1.59

Click For Price and Specs

G022304

G022304 (60309) Washer Flat 1/2 Zinc Generac Magnum MTP6SZ Trash Pump

Your Price: $10.23

Click For Price and Specs
